HBTS60.10.130R --60m3/hr

Parameter Name

Unit

HBTS60.10.130R

Overall performance

Max. Concrete Output

M³/h

60

Concrete Pumping Pressure

Mpa

13

The form of Distribution valve

S pipe valve

Concrete Cylinder

Spec.(bore*stroke)

mm

￠200*1600

Hopper Capacity

L

680

Diameter of Pump exit

mm

180

Hopper Height

mm

1450

Max. Delivery Distance (Vertical/ Horizontal)

100/600

Power
system

The Model of Diesel Engine

DEUTZ(WEICHAI)

Engine Power

kW

130

Rated Speed

r/min

2200

Hydraulic Circuit Form

Opened-circuit

Hydraulic System

Hydraulic oil tank capacity

L

580

Pump model

Kawasaki(Japan)

Overall Dimension(L*W*H))

mm

6000*2160*2600

Total Weight

Kg

6400

Pipe

m

150
